Home>> Frequency Multiplier>> MMD-0415HPSM

MMD-0415HPSM

Surface Mount from Marki Microwave

Frequency Doubler, MMIC, 2 to 7.5 GHz (Input) , 4 to 15 GHz (output), 11 dB, SMT

Status: Featured | Data Sheet:

| RoHS Compliance: Rohs Compliant

The MMD-0415HPSM is a MMIC doubler fabricated with GaAs Schottky diodes. This part operates over a 2 to 7.5 GHz input frequency range or a doubled output frequency range of 4 to 15 GHz. It features excellent conversion loss, superior isolations, and harmonic suppressions across a broad bandwidth. It is available as a 3x3mm QFN and connectorized evaluation board.

Part Number: MMD-0415HPSM
Manufacturer: Marki Microwave
Frequency Min: 2 GHz
Frequency Max: 15 GHz
Conversion Gain: 11 dB
Package: SMT
Type: Doubler
Active/Passive: Passive

No Content Available

Part Function	Part Number	Description
Evaluation Board	EVB-MMD-0415HP Marki Microwave	Evaluation Board for MMD-0415HPSM

Technical Inquiry Request for MMD-0415HPSM Frequency Multiplier

Fields marked with * are required.

Product Specifications For MMD-0415HPSM Frequency Multiplier

Part Number: MMD-0415HPSM Manufacturer: Marki Microwave Product Description: Frequency Doubler, MMIC, 2 to 7.5 GHz (Input) , 4 to 15 GHz (output), 11 dB, SMT

Design Information

* Project:

* Application:

Production Date:

Additional Requirements:

Contact Information

* Email Address:

* Phone Number:

*First Name:

* Last Name:

* Company Function:

* Company:

Job Title:

* Country:

* Zip / Postal Code:

* City:

* State or Province:

Availability

In Stock

Need products sooner?

Request a Delivery Quote

Pricing

Quantity

Price

1 - 4

$87.11

5 - 9

$71.27

Request a Pricing Quote for greater quantities

Product Notices

No Current Notices
