Home>> RF Coupler>> 715-30-1.650W

715-30-1.650W

RF Coupler from MECA

Directional Coupler, 30dB, 0.800-2.500 GHz, N-F, 500W

Status: Standard | Data Sheet:

| RoHS Compliance: Rohs Compliant

Part Number: 715-30-1.650W
Manufacturer: MECA
Type: Directional
Min Frequency: 800 MHz
Max Frequency: 2500 MHz
Coupling Factor: 30 dB
CW Power: 500 W
Package Style: Connectorized
Connector Type: N(f)

No Content Available

Technical Inquiry Request for 715-30-1.650W RF Coupler

Fields marked with * are required.

Product Specifications For 715-30-1.650W RF Coupler

Part Number: 715-30-1.650W Manufacturer: MECA Electronics, Inc. Product Description: Directional Coupler, 30dB, 0.800-2.500 GHz, N-F, 500W

Design Information

* Project:

* Application:

Production Date:

Additional Requirements:

Contact Information

* Email Address:

* Phone Number:

*First Name:

* Last Name:

* Company Function:

* Company:

Job Title:

* Country:

* Zip / Postal Code:

* City:

* State or Province:

Availability

In Stock

Need products sooner?

Request a Delivery Quote

Pricing

Quantity

Price

$279.00

Request a Pricing Quote for greater quantities

Product Notices

No Current Notices
