Home>> Amplifier>> AMM-7200CH

AMM-7200CH

Bare Die from Marki Microwave

Amplifier, Driver, 12 to 46 GHz, 18 dB, +21.5 dBm, Chip

Status: No new designs | Data Sheet:

| RoHS Compliance: Rohs Compliant

Part Number: AMM-7200CH
Manufacturer: Marki Microwave
Export Status:
Type: Broadband, LO Drive
Frequency Min: 12 GHz
Frequency Max: 46 GHz
P1dB: 19 dBm
Psat: 21.5 dBm
Gain: 18 dB
IP3: 29 dBm
Noise Figure: 6.3 dB
Return Loss Input: 19 dB
Return Loss Output: 18 dB
Process: GaAs

No Content Available

Part Function	Part Number	Description
Replacement	AMM-7200ACH Marki Microwave	Amplifier, Driver, 12 to 46 GHz, 18 dB, +19 dBm, Chip
