Home>> RF Power Transistor>> ART1K6PHGY

ART1K6PHGY

RF Power Transistor from Ampleon

RF Power Transistor, 0.001 to 0.45 GHz, 1600 W, 27.3 dB, 55 V, OMP1230-4G-1, LDMOS

Status: Standard | Data Sheet:

| RoHS Compliance: Rohs Compliant

Based on Advanced Rugged Technology (ART), this 1600 W LDMOS RF power transistor has been designed to cover a wide range of applications for ISM, broadcast and communications. The unmatched transistor has a frequency range of 1 MHz to 450 MHz.

Features and Benefits:

High breakdown voltage enables class E operation at VDS = 48 V
Suitable for VDS = 50 and 55 V
Qualified up to a maximum of VDS = 55 V
Characterized from 30 V to 55 V for extended power range
Easy power control
Integrated dual sided ESD protection enables class C operation and complete switch off of the transistor
Excellent ruggedness with no device degradation
High efficiency
Excellent thermal stability
Designed for broadband operation

Applications:

Industrial, scientific and medical applications
Plasma generators
MRI systems
CO2 lasers
Particle accelerators
Broadcast
FM radio
VHF TV
Communications
Non cellular communications
UHF radar

Part Number: ART1K6PHGY
Manufacturer: Ampleon
Frequency Min: 0.001 GHz
Frequency Max: 0.45 GHz
Output Power: 1600 W
Gain: 27.3 dB
% Typ Efficiency: 74.2
Supply Voltage: 55 V
Package: OMP1230-4G-1
Process: LDMOS
Type: RF Power Discrete Transistors

No Content Available

Part Function	Part Number	Description
Complementary Product	ART1K6FHU Ampleon	RF Power Transistor, 0.001 to 0.425 GHz, 1600 W, 28 dB, 55 V, SOT539AN, LDMOS
Complementary Product	ART1K6PHGZ Ampleon	RF Power Transistor, 0.001 to 0.45 GHz, 1600 W, 27.3 dB, 55 V, OMP1230-4G-1, LDMOS
Complementary Product	ART35FEU Ampleon	RF Power Transistor, 0.001 to 0.65 GHz, 35 W, 31 dB, 65 V, SOT467C, LDMOS
