EV90A009

SuRF RF from CML Microcircuits

Evaluation Board for the CMX90A009QK

Status: Standard | Data Sheet:

| RoHS Compliance:

The EV90A009 is the evaluation board for CMX90A009, tuned for 400-470MHz.

The CMX90A009 is a high efficiency two-stage GaAs HBT driver amplifier in a thermally enhanced plastic DFN package, delivering +40.0 dBm (10 W) of output power with >60 % efficiency at 435 MHz and 7.4 V.

CMX90A009 requires external matching at both input and output to optimize performance for each application and frequency band.

Wide supply voltage range of 6 – 9.5 V make it suitable for a variety of applications and enable direct connection to dual-cell Lithium batteries and on-chip active bias maintains operation over temperature.

CMX90A009 is intended as the output stage in a high-power amplifier, combined with CMX90A007 driver to provide a complete line-up solution.

Features

PCB consists of single-layer FR-4 with a total thickness of 0.5mm attached to an aluminium carrier.
EV90A009 PCB measures 41mm x 41mm
Microstrip RF input and output width is 1.00mm

Part Number: EV90A009
Manufacturer: CML Microcircuits

No Content Available

Part Function	Part Number	Description
Evaluation Board	CMX90A009QK CML Microcircuits	Power Amplifier, 136 to 1000 MHz, 10W, 17 dB
