F1485

Amplifier from Axiro Semiconductor Inc.

Amplifier - Linear Driver, 2.3 - 5GHz, 28dBm, 36dB, QFN 3x3mm

Status: Featured | Datasheet: Request Data Sheet | RoHS Compliance: Rohs Compliant

1/2W HIGH GAIN PRE-DRIVER AMPLIFIER

❖ High Gain and Linearity with Wide Bandwidth
❖ Excellent for both FDD/TDD 5G Sub 6GHz applications
❖ Low power TDD switching Standby mode feature

• Frequency Band :
2300MHz – 5000MHz
• 5V supply with ICQ = 120mA
• 36dB Gain at 3.5GHz
• P1dB = 28dBm@3.5GHz;
• OIP3 = 33dBm
• ACPR:
43dBc @ 3.5GHz
BW=100MHz, PAR=8.5dB, Pout=15dBm
• Up to +115C TCB operating temp
• 50Ω single end input/output impedance
• 3x3mm QFN 16pin. Fully compatible with F1485L

Part Number: F1485
Manufacturer: Axiro Semiconductor Inc.
Type: Amplifiers
Frequency Min: 2.3 GHz
Frequency Max: 5 GHz
P1dB: 28 dBm
Gain: 36 dB
IP3: 33 dBm
Supply Voltage \ Vd Min: 5 V
Quiescent Current \ Id: 120 mA
Package: QFN 3x3mm

Tariff Notice

Product may be included on Section 301 Tariff List and subject to applicable tariff charges.
