Home>> Variable Gain Amplifier>> F4481

F4481

Variable Gain Amplifier from Axiro Semiconductor Inc.

Variable Gain Amplifier -- 0.4 to 1.1, 28dB, 17dBm, 35dBm, 131mA, 3.3V

Status: Standard | Datasheet: Request Data Sheet | RoHS Compliance: Rohs Compliant

The F4481 is a 400MHz to 1100MHz Quad Path TX DVGA outfitted with 100Ω differential inputs and 50Ω single-ended outputs. The device is part of a complete family of VGAs targeting FDD and TDD applications within the 400MHz to 4200MHz frequency range. Using a single 3.3V power supply and only 520mA of ICC, the F4481 provides four independent transmit paths, each with 28dB typical maximum gain, +35dBm OIP3, +17dBm output P1dB, and 5.7dB NF. Each channel includes a glitch-free digital step attenuator that reduces gain by up to 31.5dB in precise 0.5dB steps.

The F4481 is packaged in an 8 × 8 mm 56-LGA, with matched 100Ω differential input and 50Ω single-ended output impedances for ease of integration into the signal path.

Independent quad channels for FDD TX applications
400MHz to 1100MHz
28dB typical max gain at 900MHz
- Precise SPI-controlled Glitch-Free™ gain adjustment
31.5dB gain range with 0.5dB step size
5.7dB NF at 900MHz
+35dBm OIP3 at 900MHz
+17dBm output P1dB at 900MHz
3.3V supply voltage
ICC = 524mA
100Ω differential input impedances
50Ω single-ended output impedances
1.8V and 3.3V logic support
Independent channel standby modes for power savings
Operating temperature (TEP) range: -40°C to +115°C
8 × 8 mm, 56-LGA package

Part Number: F4481
Manufacturer: Axiro Semiconductor Inc.
Frequency Range: 0.45 to 1.1 GHz
Gain: 28 dB
OP1dB: 17 dBm
OIP3: 35 dBm
Bias Current: 131 mA
Bias Voltage: 3.3 V
