Home>> RF Filter - Low Pass>> MFLP-00045GSM2

MFLP-00045GSM2

Surface Mount from Marki Microwave

Filter, Low Pass, Passive Glass, 4900 MHz, SMT (GSM2)

Status: Featured | Data Sheet:

| RoHS Compliance: Rohs Compliant

The MFLP-00045GSM2 surface-mount lowpass filter is an ideal solution for extremely small form factor, high rejection filtering. The MFLP-00045GSM2 features a 4.9 GHz 3 dBc cutoff and 25 dB passband return loss. Its advanced glass substrate technology allows production of smaller filter constructions that replace larger form factor circuit board constructions. Tight fabrication ensures tighter unit-to-unit consistency than legacy filter technologies, supporting accurate simulation with the provided S2P data. The MFLP-00045GSM2 is offered in a 4.27 × 4.00 mm package.

Part Number: MFLP-00045GSM2
Manufacturer: Marki Microwave
Filtering Technology: Glass Substrate
Cut Off Frequency: 4900 MHz
Return Loss Typ: 25 dB
High Side Rejection: 30 dBc
High Side Rejection: 5450 MHz
Package: SMT
Length: 4.25 mm
Width: 4 mm

No Content Available

Part Function	Part Number	Description
Evaluation Board	EVB-MFLP-00045G Marki Microwave	Evaluation Board for MFLP-00045GSM2
