MM1-0626SCSP2

Surface Mount from Marki Microwave

RF Mixer, Double-Balanced, 6000 to 26000 MHz (RF/LO), +13 to +24 dBm (LO Drive), SMT-SCSP2

Status: Featured | Data Sheet:

| RoHS Compliance: Rohs Compliant

The MMPX-00001PSM is a MMIC surface mount quadplexer capable of multiplexing DC-4 GHz / 6-8 GHz / 10-12 GHz / 14-16 GHz signals. Passive GaAs MMIC technology allows production of smaller filter constructions that replace larger form factor circuit board constructions. Tight fabrication tolerances allow for less unit-to-unit variation than traditional filter technologies. The MMPX-00001PSM is available as a 6x6mm QFN. Low unit to unit variation allows for accurate simulations using the provided SnP files taken from measured production units.

Part Number: MM1-0626SCSP2
Manufacturer: Marki Microwave
Type: Double Balanced
RF Frequency Range Min: 6000 MHz
RF Frequency Range Max: 26000 MHz
Operating LO Frequency Range Min: 6000 MHz
Operating LO Frequency Range Max: 26000 MHz
LO Drive Min: 13 dBm
LO Drive Max: 24 dBm
IF Frequency Min: 0 MHz
IF Frequency Max: 9000 MHz
IIP3: 25 dBm
Isolation LO-RF: 45 dB
Isolation LO-IF: 35 dB
Isolation RF-IF: 40 dB
Package: SMT

No Content Available

Part Function	Part Number	Description
Evaluation Board	EVB-MM1-0626S Marki Microwave	Evaluation Board for MM1-0626SCSP2

Technical Inquiry Request for MM1-0626SCSP2 RF Mixer

Fields marked with * are required.

Product Specifications For MM1-0626SCSP2 RF Mixer

Part Number: MM1-0626SCSP2 Manufacturer: Marki Microwave Product Description: RF Mixer, Double-Balanced, 6000 to 26000 MHz (RF/LO), +13 to +24 dBm (LO Drive), SMT-SCSP2

Design Information

* Project:

* Application:

Production Date:

Additional Requirements:

Contact Information

* Email Address:

* Phone Number:

*First Name:

* Last Name:

* Company Function:

* Company:

Job Title:

* Country:

* Zip / Postal Code:

* City:

* State or Province:

Availability

In Stock

Need products sooner?

Request a Delivery Quote

Pricing

Quantity

Price

1 - 4

$148.44

5 - 9

$121.45

Request a Pricing Quote for greater quantities

Product Notices

No Current Notices
