Home>> RF Mixer>> MM1-1453LSM-2

MM1-1453LSM-2

Surface Mount from Marki Microwave

RF Mixer, Double-Balanced, 14000 to 53000 MHz (RF/LO), +7 to +15 dBm (LO Drive), SMT-L2

Status: Standard | Data Sheet:

| RoHS Compliance: Rohs Compliant

The MM1-1453LSM is a GaAs MMIC double balanced mixer that features excellent conversion loss, superior isolations and spurious performance across a broad bandwidth. MM1-1453LSM works well as both an up and down converter and is recommend for low power applications that demand high linearity. If a higher LO drive is required, the MM1-1453HSM offers similar specifications in the same surface mount package. The MM1-1453LSM is available in a 4x4 mm QFN package. Evaluation boards are also available. The AMM-6702SM is recommended as the ideal LO driver for the MM1-1453LSM.

Part Number: MM1-1453LSM-2
Manufacturer: Marki Microwave
Export Status:
Type: Double Balanced
RF Frequency Range Min: 14000 MHz
RF Frequency Range Max: 53000 MHz
Operating LO Frequency Range Min: 14000 MHz
Operating LO Frequency Range Max: 53000 MHz
LO Drive Min: 7 dBm
LO Drive Max: 15 dBm
IF Frequency Min: 0 MHz
IF Frequency Max: 22000 MHz
IIP3: 13 dBm
Isolation LO-RF: 56 dB
Isolation LO-IF: 35 dB
Isolation RF-IF: 49 dB
Package: SMT

No Content Available

Part Function	Part Number	Description
Evaluation Board	EVAL-MM1-1453L Marki Microwave	Evaluation Board for MM1-1453LSM-X
Complementary Product	ADM-8007PSM Marki Microwave	Amplifier, 2 to 40 GHz , 23 dB, +24 dBm, SMT
Complementary Product	AMM-6702SM Marki Microwave	Amplifier, LO Driver, 20 to 50 GHz, 24 dB, +19 dBm, SMT

Technical Inquiry Request for MM1-1453LSM-2 RF Mixer

Fields marked with * are required.

Product Specifications For MM1-1453LSM-2 RF Mixer

Part Number: MM1-1453LSM-2 Manufacturer: Marki Microwave Product Description: RF Mixer, Double-Balanced, 14000 to 53000 MHz (RF/LO), +7 to +15 dBm (LO Drive), SMT-L2

Design Information

* Project:

* Application:

Production Date:

Additional Requirements:

Contact Information

* Email Address:

* Phone Number:

*First Name:

* Last Name:

* Company Function:

* Company:

Job Title:

* Country:

* Zip / Postal Code:

* City:

* State or Province:

Availability

In Stock

Need products sooner?

Request a Delivery Quote

Pricing

Quantity

Price

1 - 4

$341.04

5 - 9

$279.04

Request a Pricing Quote for greater quantities
