MMIQ-0205HSM-2

Surface Mount from Marki Microwave

RF Mixer, MMIC IQ, 1750 to 5000 MHz (RF/LO), +14 to +20 dBm (LO Drive), SMT-H2

Status: Standard | Data Sheet:

| RoHS Compliance: Rohs Compliant

Part Number: MMIQ-0205HSM-2
Manufacturer: Marki Microwave
Type: Double Balanced IQ
RF Frequency Range Min: 1750 MHz
RF Frequency Range Max: 5000 MHz
Operating LO Frequency Range Min: 1750 MHz
Operating LO Frequency Range Max: 5000 MHz
LO Drive Min: 14 dBm
LO Drive Max: 20 dBm
IF Frequency Min: 0 MHz
IF Frequency Max: 2000 MHz
Package: SMT

No Content Available

Part Function	Part Number	Description
Evaluation Board	EVAL-MMIQ-0205H Marki Microwave	Evaluation Board for MMIQ-0205HSM-X
Complementary Product	ADM-8007PSM Marki Microwave	Amplifier, 2 to 40 GHz , 23 dB, +24 dBm, SMT
