Home>> RF Mixer>> MMIQ-1040LSM-2

MMIQ-1040LSM-2

Surface Mount from Marki Microwave

RF Mixer, MMIC IQ, 10000 to 40000 MHz (RF/LO), 10 to 22 dBm (LO Drive), SMT

Status: Featured | Data Sheet:

| RoHS Compliance: Rohs Compliant

MMIQ-1040LSM is a high linearity, passive GaAs MMIC IQ mixer. This is an ultra-broadband mixer spanning 10 to 40 GHz on the RF and LO ports with an IF from DC to 10 GHz. Up to 50 dB of image rejection is available due to the excellent phase and amplitude balance of its on-chip LO quadrature hybrid. It operates with a low +10dBm LO drive. Both surface mount QFNs and evaluation boards are available.

Part Number: MMIQ-1040LSM-2
Manufacturer: Marki Microwave
Type: Double Balanced IQ
RF Frequency Range Min: 10000 MHz
RF Frequency Range Max: 40000 MHz
Operating LO Frequency Range Min: 10000 MHz
Operating LO Frequency Range Max: 40000 MHz
LO Drive Min: 10 dBm
LO Drive Max: 22 dBm
IF Frequency Min: 0 MHz
IF Frequency Max: 10000 MHz
IIP3: 17 dBm
Isolation LO-RF: 50 dB
Isolation LO-IF: 50 dB
Isolation RF-IF: 45 dB

No Content Available

Part Function	Part Number	Description
Evaluation Board	EVAL-MMIQ-1040L Marki Microwave	Evaluation Board for MMIQ-1040LSM-X
Complementary Product	ADM-8007PSM Marki Microwave	Amplifier, 2 to 40 GHz , 23 dB, +24 dBm, SMT

Technical Inquiry Request for MMIQ-1040LSM-2 RF Mixer

Fields marked with * are required.

Product Specifications For MMIQ-1040LSM-2 RF Mixer

Part Number: MMIQ-1040LSM-2 Manufacturer: Marki Microwave Product Description: RF Mixer, MMIC IQ, 10000 to 40000 MHz (RF/LO), 10 to 22 dBm (LO Drive), SMT

Design Information

* Project:

* Application:

Production Date:

Additional Requirements:

Contact Information

* Email Address:

* Phone Number:

*First Name:

* Last Name:

* Company Function:

* Company:

Job Title:

* Country:

* Zip / Postal Code:

* City:

* State or Province:

Availability

In Stock

Need products sooner?

Request a Delivery Quote

Pricing

Quantity

Price

1 - 4

$426.82

5 - 9

$341.46

Request a Pricing Quote for greater quantities

Product Notices

No Current Notices
