MMIQA-0626HPSM

Surface Mount from Marki Microwave

RF Mixer, MMIC IQ, Integrated Amplifier, Double-Balanced, 6000 to 26000 MHz (RF/LO), -2 to +8 dBm (LO Drive), SMT-H

Status: Featured | Data Sheet:

| RoHS Compliance: Rohs Compliant

The MMIQA-0626HPSM is a versatile, robust, and broadband IQ mixer with an integrated broadband LO driver amplifier. The MMIQA-0626HPSM is ideal for IQ, single sideband, and image reject mixing applications with wide bandwidths. The integrated LO driver amplifier allows for operation with LO powers as low as -2dBm while retaining exceptional conversion loss and linearity.

Part Number: MMIQA-0626HPSM
Manufacturer: Marki Microwave
Type: Double Balanced, MMIC IQ
RF Frequency Range Min: 6000 MHz
RF Frequency Range Max: 26000 MHz
Operating LO Frequency Range Min: 6000 MHz
Operating LO Frequency Range Max: 26000 MHz
LO Drive Min: -2 dBm
LO Drive Max: 8 dBm
IF Frequency Min: 0 MHz
IF Frequency Max: 6000 MHz
IIP3: 26 dBm
Supply Voltage: 5 V
Isolation RF-IF: 35 dB
Package: SMT

No Content Available

Part Function	Part Number	Description
Evaluation Board	EVB-MMIQA-0626H Marki Microwave	Evaluation Board for MMIQA-0626HPSM

Technical Inquiry Request for MMIQA-0626HPSM RF Mixer

Fields marked with * are required.

Product Specifications For MMIQA-0626HPSM RF Mixer

Part Number: MMIQA-0626HPSM Manufacturer: Marki Microwave Product Description: RF Mixer, MMIC IQ, Integrated Amplifier, Double-Balanced, 6000 to 26000 MHz (RF/LO), -2 to +8 dBm (LO Drive), SMT-H

Design Information

* Project:

* Application:

Production Date:

Additional Requirements:

Contact Information

* Email Address:

* Phone Number:

*First Name:

* Last Name:

* Company Function:

* Company:

Job Title:

* Country:

* Zip / Postal Code:

* City:

* State or Province:

Availability

In Stock

Need products sooner?

Request a Delivery Quote

Pricing

Quantity

Price

25 - 99

$324.87

100 - 499

$299.94

Request a Pricing Quote for greater quantities

Product Notices

No Current Notices
