Home>> RF Mixer>> MT3D-0325HCSM-2

MT3D-0325HCSM-2

Surface Mount from Marki Microwave

RF Mixer, T3 w/ Differential IF, 3000 to 25000 MHz (RF/LO), +17 to +23 dBm (LO Drive), Ceramic, SMT-H2

Status: Featured | Data Sheet:

| RoHS Compliance: Rohs Compliant

MT3D-0325HCSM is a GaAs MMIC triple balanced mixer with high dynamic range and low conversion loss. This mixer belongs to the T3 family which offers high IP3, P_1dB, and broad operating bandwidths for applications in the S through K bands. The MT3D-0325HCSM has on-chip baluns for the LO and RF ports, while offering differential ports on the IF for flexible operation with an external balun or differential interface. The MT3D-0325HCSM is available in a 4x4 mm QFN package.

Part Number: MT3D-0325HCSM-2
Manufacturer: Marki Microwave
Type: Differential IF Mixers, T3 High Linearity, Triple Balanced
RF Frequency Range Min: 3000 MHz
RF Frequency Range Max: 25000 MHz
Operating LO Frequency Range Min: 3000 MHz
Operating LO Frequency Range Max: 25000 MHz
LO Drive Min: 17 dBm
LO Drive Max: 23 dBm
IF Frequency Min: 0 MHz
IF Frequency Max: 6000 MHz
IIP3: 25 dBm
Isolation LO-RF: 33 dB
Isolation LO-IF: 43 dB
Isolation RF-IF: 43 dB
Package: SMT

No Content Available

Part Function	Part Number	Description
Evaluation Board	EVB-MT3D-0325HC Marki Microwave	Evaluation Board for MT3D-0325HCSM-2
Complementary Product	ADM-8007PSM Marki Microwave	Amplifier, 2 to 40 GHz , 23 dB, +24 dBm, SMT

Technical Inquiry Request for MT3D-0325HCSM-2 RF Mixer

Fields marked with * are required.

Product Specifications For MT3D-0325HCSM-2 RF Mixer

Part Number: MT3D-0325HCSM-2 Manufacturer: Marki Microwave Product Description: RF Mixer, T3 w/ Differential IF, 3000 to 25000 MHz (RF/LO), +17 to +23 dBm (LO Drive), Ceramic, SMT-H2

Design Information

* Project:

* Application:

Production Date:

Additional Requirements:

Contact Information

* Email Address:

* Phone Number:

*First Name:

* Last Name:

* Company Function:

* Company:

Job Title:

* Country:

* Zip / Postal Code:

* City:

* State or Province:

Availability

In Stock

Need products sooner?

Request a Delivery Quote

Pricing

Quantity

Price

1 - 4

$309.40

5 - 9

$257.83

Request a Pricing Quote for greater quantities

Product Notices

No Current Notices
