Home>> RF Mixer>> MT3L-0113HCH-2

MT3L-0113HCH-2

Bare Die from Marki Microwave

RF Mixer, High Dynamic Range, 1500 to 13000 MHz (RF/LO), +15 to +25 dBm (LO Drive), Chip-H2

Status: Standard | Data Sheet:

| RoHS Compliance: Rohs Compliant

Part Number: MT3L-0113HCH-2
Manufacturer: Marki Microwave
Type: T3 High Linearity, Triple Balanced
RF Frequency Range Min: 1500 MHz
RF Frequency Range Max: 13000 MHz
Operating LO Frequency Range Min: 1500 MHz
Operating LO Frequency Range Max: 13000 MHz
LO Drive Min: 15 dBm
LO Drive Max: 25 dBm
IF Frequency Min: 250 MHz
IF Frequency Max: 5000 MHz
IIP3: 31 dBm
Isolation LO-RF: 43 dB
Isolation LO-IF: 41 dB
Isolation RF-IF: 39 dB
Package: Chip

No Content Available

Part Function	Part Number	Description
Complementary Product	ADM-5974CH Marki Microwave	Amplifier, Broadband, 0 to 35 GHz, 14 dB, +22 dBm. Chip

Technical Inquiry Request for MT3L-0113HCH-2 RF Mixer

Fields marked with * are required.

Product Specifications For MT3L-0113HCH-2 RF Mixer

Part Number: MT3L-0113HCH-2 Manufacturer: Marki Microwave Product Description: RF Mixer, High Dynamic Range, 1500 to 13000 MHz (RF/LO), +15 to +25 dBm (LO Drive), Chip-H2

Design Information

* Project:

* Application:

Production Date:

Additional Requirements:

Contact Information

* Email Address:

* Phone Number:

*First Name:

* Last Name:

* Company Function:

* Company:

Job Title:

* Country:

* Zip / Postal Code:

* City:

* State or Province:

Availability

In Stock

Need products sooner?

Request a Delivery Quote

Pricing

Quantity

Price

1 - 4

$234.98

5 - 9

$195.82

Request a Pricing Quote for greater quantities

Product Notices

No Current Notices
