Home>> FET Controller>> PE29102

PE29102

High-speed FET Driver

UltraCMOS® High-speed FET Driver, 33 MHz

Status: Discontinued | Data Sheet:

| RoHS Compliance: Rohs Compliant

Key Features

•High- and low-side FET drivers •Dead-time control •Fast propagation delay, 9 ns •Tri-state enable mode •Sub-nanosecond rise and fall time •2A/4A peak source/sink current •Packaging: Flip chip

Description

NOT RECOMMENDED FOR NEW DESIGNS (NRND) This product is not recommended for new designs. For more information, please contact your local sales representative. The PE29102 is an integrated high-speed driver designed to control the gates of external power devices, such as gallium nitride (GaN) FETs. The outputs of the PE29102 are capable of providing switching transition speeds in the sub-nanosecond range for switching applications up to 40 MHz. The PE29102 is optimized for matched dead time and offers best-in-class propagation delay to improve system bandwidth. High switching speeds result in smaller peripheral components and enable innovative designs for applications such as Class D audio and wireless charging.

Part Number: PE29102
Manufacturer: pSemi

	Datasheet
	Material Declaration
	RoHS Compliance Certificate
	REACH Compliance Certificate
	Schematic/B.O.M.
	Gerber Files
	EVK Manual
	Class D Audio Case Study
	Application Note: PE29101/102 Footprint Requirements
	Application Note: Using Peregrine’s High-Speed FET Drivers
	Application Note: Using the PE29102 as a Power-up Sequencer
	Application Note: Using the PE29102 Driver as a Differential
	Application Note: Class D Audio Using the PE29102

Part Function	Part Number	Description
Design Kit	EK29102-03 pSemi	Evaluation Kit for PE29102
Complementary Product	PE29101 pSemi	UltraCMOS® High-speed FET Driver, 40 MHz
