Home>> RF Filter - Band Pass>> SEWB3500SP200K

SEWB3500SP200K

High Power Small Form Factor C band Filter

Filter, Ceramic Waveguide, 3500 MHz, 200 MHz BW

Status: Standard | Data Sheet:

| RoHS Compliance: Rohs Compliant

The SEWB3500SP200K is a high power, low loss filter with small form factor, ideally suited for use in n77 C band applications. Covering 200 MHz of C Band and with a power handling of 12 Watts Average and 120 Watts Peak, and with a footprint of just 20mm x 30mm, the filter offers excellent rejection performance, achieving 20dB of rejection just 40 MHz from the passband edge. This filter is designed with the objective of maximising out of band rejection. For lower passband insertion loss, consideration should be given to the SEWB3500SP200SM.

Part Number: SEWB3500SP200K
Manufacturer: Sangshin
Filtering Technology: Ceramic Waveguide
Center Frequency: 3500 MHz
Bandwidth: 200 MHz
Insertion Loss TYP: 1.4 dB
Return Loss Typ: 15 dB
Low Side Rejection: 20 dB
Low Side Rejection: 3360 MHz
High Side Rejection: 20 dB
High Side Rejection: 3640 MHz
Package: SMT
Length: 32 mm
Width: 20 mm
Height: 8.1 mm
